Overview
The 400C is a 33% duty cycle compressor that works quickly and efficiently putting out a massive 2.54 CFM flow at zero PSI head pressure. Features include a standard 1/4” NPT stainless steel braided leader hose with inline check valve and insulated wiring for simple installation. Must be used with a 150 PSI or lower pressure, non-adjustable pressure switch when used with an air tank.
Features
- Oil-less Design
- High Performance PTFE Piston Ring
- Stainless Steel Valves
- Moisture Dust Resistant
- Gearless Direct Drive Motor
- Anodized Aluminum Alloy Cylinder
- Automatic Reset Thermal Overload Protector
- Mounting Plates with Vibration Isolators
- Inline Check Valve
- Remote Mountable Intake Filter Assembly
Specifications
- Permanent Magnetic Motor
- 24-Volt
- Duty Cycle: 33% @ 100 PSI
- Max. Working Pressure: 150 PSI
- Max. Air Tank Size: 5.0 Gallon
- Amp Draw: 15 Amps
- Ingress Protection Rating: IP67
- Dimensions: 9 inch L x 4 inch W x 6.75 inch H
- Net Weight: 8.65 lbs.
