Onboard Air System | Viair | Continuous Duty | 200 PSI

SKU 20002

$628.95 Free Ship!
Spin UpSpin Down


Product Specifications

  • Amp Draw:23 amps
  • Compressor:Heavy Duty
  • Duty Cycle:100 percent
  • Gauge Type:Analog
  • View more
  • Typically ships in 2 to 3 business days.

Product Specs for Viair 20002

Ask an Expert

customer service Our Michigan based experts can help.

1.800.358.4751
Email
Hours
M-F 7:00AM - 11:00PM EST
Sat 8:00AM - 1:00PM EST

Viair 20002 Details

Viair 20002 continuous duty onboard air compressor system features a 200 PSI rated, 100% duty cycle 485C CE compressor, 2.5 gallon air tank, and all components needed to install a working system capable of inflating tires of virtually any size.

Features

  • 2.5 Gallon VIAIR Air Tank (200 PSI)
  • 485C Stealth Black VIAIR Compressor w/ Thermal Overload Protector
  • Digital Tire Inflation Gun with 180 PSI Gauge
  • 30 foot Inside Braided Black Coil Hose with Quick Connects
  • 1/4 inch NPT Quick Connect Stud (F)
  • 1/4 inch NPT Quick Connect Coupler (F)
  • Dash Panel Gauge with ON/OFF Switch
  • Sealed Pressure Switch (165 PSI on, 200 PSI off)
  • Reducer 1/8 inch NPT (F) to 1/4” NPT (M)
  • Reducer 3/8 inch NPT (F) to 1/4” NPT (M)
  • 1/4 inch NPT 250 PSI Safety Valve
  • 1/4 inch NPT Drain Cock
  • (3) 1/4 inch NPT Compression Fittings
  • 4 inch Strip of Grommet Material
  • 20 foot 12-Gauge Wire with Inline Fuse Holder
  • Electrical Connections
  • Accessory Airline

Specifications

  • 12-Volt
  • Permanent Magnetic Motor
  • Duty Cycle: 100% @ 200 PSI
  • Max. Working Pressure: 200 PSI
  • Max. Air Tank Size: 5.0 Gallon
  • Combined Max. Amp Draw: 23 Amps
  • Ingress Protection Rating: IP67
  • Dimensions: 10.63″L x 4.1″W x 6.44″H
  • Net Weight: 11.10 lbs.

Customer Q&A - Viair 20002


Viair

Viair Corporation offers a full line air compressors and air accessories of unparalleled quality for on the road, off-road and industrial applications. Viair air products have unmatched quality to survive even the harshest clime and the most extreme conditions while consistently delivering a level of performance unknown by other renewable air sources. Viair is the name you can trust because it is you vital air source. For more information on Viair and their top of the line air source products, visit their website at viaircorp.com

Viair Corporation Warranty

1 Year Limited Warranty

On VIAIR compressors. VIAIR warrants their products against defects in materials and workmanship.

What the warranty does not cover

Normal wear and tear over time, damage from abuse or neglect, corrosion, and damage resulting from accidents is not covered. Improper installation. Any alteration of products beyond the included installation instructions will void the warranty. Cosmetic finish is not covered.

You can view the full details of Viair’s warranty here.

How to get service

Contact VIAIR corporation at 1-949-585-0011.
Fax a copy of your receipt to (949) 585-0188 or email the receipt to customerservice@viaircorp.com.
